JR 12 (UJ1DX8J122DK12175)
12-1
In category Trailer-mounted
The values in the column labeled associated with working diagram.
|
Parameter
|
Identification
|
Value
|
|---|---|---|
| Manufacturer | Denka-Lift | |
| Type | přívěsné | |
| Field of application | zpevněný podklad | |
| Design | teleskopická | |
| Working height - radius (m) | A | 12 |
| Maximum outreach (m) | B | 6.7 |
| Cage load capacity (kg) | 120 | |
| Total machine weight (kg) | 1000 | |
| Drive | benzín / 230 V | |
| Cage dimensions (m) | D x C | 0,9 x 0,6 |
| Cage extension - prolongation (m) | E | - |
| Setting dimensions (m) | F x G | 3,6 x 3,6 |
| Clearance width (m) | H (I) | 1,4 (0,75) |
| Clearance height (m) | J | 1,84 (2,1) |
| Length (m) | K | 5,68 (5,05) |
| Levelling supports | 4x |
